Technical specifications

Photo Sensor 5MP IMX335

Lens 4mm, F/1.6

Photo resolution 36M / 30M / 24M / 20M / 16M / 12M / 8M / 5M / 3M

Photo file extension .JPG

Time lapse 5 / 30min , 1 / 2 / 3 / 6 / 12 / 24 h

Multishot mode Up to 9 photos/capture

Stamp Date, time, temperature (°C/°F) and moon phase

Video

Video resolution 4K / 2K / 1080P / 720P / VGA

Video file extension .MP4 / H.265

Video file length 5 / 10 / 30 / 60 / 90 seconds

Recording mode Colorful mode at daytime, Black and white mode at night

Operating modes Photo / Video / Photo & Video / Time lapse

Memory SD card slot (maximum supported capacity 256GB). The card is not included.

Screen TFT 2.4”

Power supply 12V 8000mAh Li-Ion battery External power supply: 12V DC

Current (Amper) 1mA(in standby) / max. 300mA

Motion sensor 1 x PIR

PIR detection angle 120°

PIR detection distance Adjustable, from 0.30 m (1 ft) to 30 m (98 ft)

IR LEDs 56

IR illumination distance Up to 30 m (98 ft)

Exposure Auto / 100 / 200 / 400

Field of view (FOV) 120°

Trigger speed 0.3 seconds

Delay between two detections 1/10 seconds, 1/3/5/10/15/30 minutes

GSM frequency 4G FDD-LTE B1 B3 B5 B7 B20 3G WCDMA B1 B5 B8 2G GSM 850/900/1800/1900

Dimensions 155 x 110 x 85 mm

Operating temperature -26°C ~ +80°C

Protection grade IP65
